Tube Trace VSX Self Regulatıng Heating Kit THERMON
TubeTrace, with “cut-to-length” VSX self-regulating heat tracing, is designed to provide freeze protection or temperature maintenance from 40°F (5°C) to 300°F (149°C) for tubing where high temperature exposure capability is possible. VSX withstands intermittent temperature exposures of 450°F (232°C). Self-regulating VSX heat tracing:
• Varies in response to the surrounding conditions along the entire length of a circuit.
• Lower risk of overheating the tube or product.
• Installed cost is lower because “cut-to-length” VSX makes end connections easy with minimal waste.
• VSX is approved for use in ordinary (non-classified) areas and hazardous (classified) areas.

CONSTRUCTION
1 Process tube(s)
2 VSX self-regulating electrical heat tracing
3 Heat reflective tape
4 Non-hygroscopic glass fiber insulation
5 Polymer outer jacket (ATP or TPU available)
PRODUCT FEATURES
• Self-regulating
• “Cut-to-length”
• Hazardous area approvals
| RATINGS | |
| Available watt densities | 5, 10, 15, 20 w/ft @ 50°F |
| 16, 33, 49, 66 w/m @ 10°C | |
| Supply voltages | 110-120 or 208-277 Vac |
| Tube temperature range | 40°F to 300°F (5°C to 149°C) |
| Max. exposure temperature | |
| Intermittent power-on | 450°F (232°C) |
| Intermittent power-off | 482°F (250°C) |
| Continuous power-off | 400°F (204°C) |
| T-rating | T3 392°F (200°C) |
