Mineral Insulated RTD with Pot Seal
Mineral Insulated RTD with Pot Seal
Mineral Insulated RTD (Pt100) with Plain Pot Seal and 1
metre lead wire
Pt100 resistance thermometers manufactured from
mineral insulated cable are suitable for use up to
temperatures of 600°C. The RTD is supplied in 3 or 6mm
diameter and is terminated using a plain pot seal, epoxy
resin filled with one metre FEP/FEP stranded 3 wire
connection. Although shown straight, mineral insulated
resistance thermometers can be bent around formers (with
a radius of three times the probe diameter) and at angles
and shapes to suit the application. They can also be
manufactured in very long lengths.
Specification
Features
- Mineral insulated cable
- Wide temperature range
- Can be formed and shaped to fit the process
- 1 metre FEP/FEP 3 wire stripped leads
- Can be made in long lengths
Application
- Aerospace
- Manufacturing processes
- Pharmaceutical and laboratory
