Heat Trace 60w/m

Max Operating Temperature Power ON
65°C (150°F)
Max Exposure Temperature Power OFF
85°C (185°F)
W/m @10°C
9, 15, 25, 32
W/ft @50°F
3, 5, 8, 10
Voltage Range
100-277 Vac
T-Rating
T6 | T5

BSX™Self-Regulating Heating Cable

Designed to provide freeze protection or process temperature maintenance to metallic and nonmetallic piping, tanks and equipment.SEE PRODUCT

Max Operating Temperature Power ON
65°C (150°F)
Max Exposure Temperature Power OFF
85°C (185°F)
W/m @10°C
49
W/ft @50°F
15
Voltage Range
100-120 or 208-240 Vac
T-Rating
T6 | T4A

RSX™ 15-2Self-Regulating Heating Cable

Designed for applications where the watt density requirements preclude the use of the standard range of BSX cables.SEE PRODUCT

Max Operating Temperature Power ON
150°C (302°F)
Max Exposure Temperature Power OFF
250°C (482°F)
W/m @10°C
10, 20, 30, 39, 49, 66
W/ft @50°F
3, 6, 9, 10, 12, 15, 20
Voltage Range
100-277 Vac
T-Rating
T3 to T6

HTSX™Self-Regulating Heating Cable

Designed specifically for process temperature maintenance or freeze protection where high temperature exposure associated with steam purging.SEE PRODUCT

Max Operating Temperature Power ON
240°C (464°F)
Max Exposure Temperature Power OFF
250°C (482°F)
W/m @10°C
10, 20, 30, 39, 49, 66
W/ft @50°F
3, 6, 9, 12, 15, 20
Voltage Range
100-277 Vac
T-Rating
T3-T6

USX™Self-Regulating Heating Cable

USX self-regulating heat tracing is specifically engineered for critical process maintenance and freeze protection applications where ultra-high temperature ratings are required. USX enables the use of ambient sensing controls for applications with continuous exposure temperatures up to 240°C (464°F). Constructed using Thermon’s unique and proven monolithic co-extrusion process, USX advances self-regulating heat tracing technology to the ultimate frontiers of performance and reliability.

The heat output of USX heat tracing varies in response to the surrounding temperature. Variations in the ambient temperature or heat lost through the thermal insulation are compensated for automatically along the entire length of a heat-traced pipe.SEE PRODUCT

Max Operating Temperature Power ON
200°C (392°F)
Max Exposure Temperature Power OFF
250°C (482°F)
W/m @10°C
16, 33, 49, 66
W/ft @50°F
5, 10, 15, 20
Voltage Range
100-277 Vac
Based on Stabilized Design
T2 to T6

VSX-HT™Self-Regulating Heating Cable

Designed specifically for process temperature maintenance or freeze protection where high maintain temperatures or high temperature exposure is required.SEE PRODUCT

Max Operating Temperature Power ON
210°C (410°F)
Max Exposure Temperature Power OFF
260°C (500°F)
W/m @10°C
16, 33, 49, 66
W/ft @50°F
5, 10, 15, 20
Voltage Range
100-277 Vac
T-Rating
T2 to T6

HPT™Power-Limiting Heating Cable

Designed specifically for medium to high process temperature maintenance or freeze protection or high temperature exposure is required.SEE PRODUCT

Max Operating Temperature Power ON
65°C (150°F)
Max Exposure Temperature Power OFF
204°C (400°F)
W/m @10°C
8, 16, 33
W/ft @50°F
2.5, 5, 10
Voltage Range
120/240 Vac
T-Rating
T3 to T6

FP™Parallel Constant Watt Heating Cable

Designed to provide consistent and reliable heat outputs regardless of circuit length.SEE PRODUCT

Rated voltage
up to 600 Vac
Max. maintenance temperature
101°C (215°F)
Max. continuous exposure temperature Power-off
232°C (215°F)

TEK™Series Constant Watt Heating Cable

Designed for long line temperature maintenance or freeze protection where circuit lengths exceed the limitations of parallel resistance heating cables.SEE PRODUCT

Rated voltage
up to 600 Vac
Max. maintenance temperature
204°C (400°F)
Max. continuous exposure temperature Power-off
260°C (500°F)

HTEK™Series Constant Watt Heating Cable

Designed where circuit lengths exceed the limitations of parallel resistance heating cables and high maintain temperatures or high temperature exposure is required.SEE PRODUCT

Rated voltage
300 & 600 Vac
Max. maintenance temperature
500°C (932°F)
Max. continuous exposure temperature
600°C (1,112°F)
Max. watt density
Up to 262 W/m (80 w/ft)

MIQ™Series Constant Watt Heating Cable

Designed for high temperature maintenance, high temperature exposure and/or high watt density applications which exceed the limitations of thermoplastic insulated cables.SEE PRODUCT

Rated voltage
up to 5 kV
Max. maintenance temperature
200°C (392°F)
Max. continuous exposure temperature Power-off
260°C (500°F)

THERMTRAC™Skin Effect Heat Tracing System

Designed as a cost-effective alternative to conventional resistance heat tracing on long pipelines by eliminating the need for an extensive power distribution system.SEE PRODUCT

Max Operating Temperature Power ON
65°C (150°F)
Max Exposure Temperature Power OFF
85°C (185°F)
W/m @10°C
9, 15, 25, 32
W/ft @50°F
3, 5, 8, 10
Voltage Range
100-277 Vac

FLXSelf-Regulating Heating Cable

Designed to provide freeze protection and temperature maintenance in ordinary – non-classified areas by replacing the heat lost through the thermal insulation into the air.SEE PRODUCT
